PRODUCT CHARACTERISTICS
A. Small size, compact structure, occupying an area of only about 1/3-1/5 of the same capacity of domestic European box, fully sealed, fully insulated structure, no insulation distance, safe and reliable transformer performance is excellent, using low loss.
B. Type S11 transformer with low noise and strong overload capacity. The product is divided into three parts: main high-voltage chamber, low-voltage chamber and transformer. It is usually arranged in "product" type. The high-voltage side can be used in loop network and terminal with V-type or T-type load switch and two-stage fuse protection. The power supply mode is flexible and reliable.
C. The high-pressure chamber is equipped with oil-wet meter, oil signal meter, pressure gauge, pressure release valve, oil discharge valve and other components to monitor the operation of transformer.
D. High-voltage feeder adopts cable plug and can be equipped with zinc oxide arrester to meet various low-voltage feeding requirements. Low-voltage metering and shunting can be added according to user's requirements.
E. Transformer uses corrugated fins to heat dissipation. After special process treatment, it has strong anti-corrosion ability and various shapes and structures. Ordinary steel plate and stainless steel plate can be selected.
PRODUCT CHARACTERISTICS
Combined Transformer (American Box Transformer)
| Model | Rated capacity (KVA) | Voltage combination tapping range | Connection group number | No-load loss (w) | Load Loss (W) | No-load current (%) | Short circuit impedance (%) | Outline size | ||
| High Voltage (KV) | Distribution range (%) | Low Voltage (KV) | Length * width * height (mm) | |||||||
| ZGS11-100 | 100 | 0.4 | 200 | 1580/1500 | 1.8 | 4 | 11830x1355x1735 | |||
| ZGS11-125 | 125 | 240 | 1890/1800 | 1.7 | 1830x1365x1735 | |||||
| ZGS11-160 | 160 | 270 | 2310/2200 | 1.6 | 1830x1375x1735 | |||||
| ZGS11-200 | 200 | 6 | 340 | 2730/2600 | 1.5 | 1830x1375x1735 | ||||
| ZGS11-250 | 250 | 6.3 | ±5 | 400 | 3200/3050 | 1.4 | 1830x1405x1735 | |||
| ZGS11-315 | 315 | 6.6 | ±2×2.5 | Yyn0 | 480 | 3830/3650 | 1.4 | 1830x1425x1735 | ||
| ZGS11-400 | 400 | 10 | Dyn11 | 570 | 4520/4300 | 1.3 | 1830x1435x1805 | |||
| ZGS11-500 | 500 | 10.5 | 680 | 5410/5150 | 1.2 | 1830x1445x1860 | ||||
| ZGS11-630 | 630 | 11 | 810 | 6200 | 1.1 | 4.5 | 1830x1445x1860 | |||
| ZGS11-800 | 800 | 980 | 7500 | 1 | 1830x1490x1860 | |||||
| ZGS11-1000 | 1000 | 1150 | 10300 | 1 | 1830x1675x2005 | |||||
| ZGS11-1250 | 1250 | 1360 | 12000 | 0.9 | 2100x1845x2035 | |||||
| ZGS11-1600 | 1600 | 1640 | 14500 | 0.8 | 2100x1885x2135 | |||||
| Note: Product shape, size and weight are data for a certain period of time, which may change due to design improvements. | ||||||||||
PRODUCT CHARACTERISTICS
A. Small size, compact structure, occupying an area of only about 1/3-1/5 of the same capacity of domestic European box, fully sealed, fully insulated structure, no insulation distance, safe and reliable transformer performance is excellent, using low loss.
B. Type S11 transformer with low noise and strong overload capacity. The product is divided into three parts: main high-voltage chamber, low-voltage chamber and transformer. It is usually arranged in "product" type. The high-voltage side can be used in loop network and terminal with V-type or T-type load switch and two-stage fuse protection. The power supply mode is flexible and reliable.
C. The high-pressure chamber is equipped with oil-wet meter, oil signal meter, pressure gauge, pressure release valve, oil discharge valve and other components to monitor the operation of transformer.
D. High-voltage feeder adopts cable plug and can be equipped with zinc oxide arrester to meet various low-voltage feeding requirements. Low-voltage metering and shunting can be added according to user's requirements.
E. Transformer uses corrugated fins to heat dissipation. After special process treatment, it has strong anti-corrosion ability and various shapes and structures. Ordinary steel plate and stainless steel plate can be selected.
PRODUCT CHARACTERISTICS
Combined Transformer (American Box Transformer)
| Model | Rated capacity (KVA) | Voltage combination tapping range | Connection group number | No-load loss (w) | Load Loss (W) | No-load current (%) | Short circuit impedance (%) | Outline size | ||
| High Voltage (KV) | Distribution range (%) | Low Voltage (KV) | Length * width * height (mm) | |||||||
| ZGS11-100 | 100 | 0.4 | 200 | 1580/1500 | 1.8 | 4 | 11830x1355x1735 | |||
| ZGS11-125 | 125 | 240 | 1890/1800 | 1.7 | 1830x1365x1735 | |||||
| ZGS11-160 | 160 | 270 | 2310/2200 | 1.6 | 1830x1375x1735 | |||||
| ZGS11-200 | 200 | 6 | 340 | 2730/2600 | 1.5 | 1830x1375x1735 | ||||
| ZGS11-250 | 250 | 6.3 | ±5 | 400 | 3200/3050 | 1.4 | 1830x1405x1735 | |||
| ZGS11-315 | 315 | 6.6 | ±2×2.5 | Yyn0 | 480 | 3830/3650 | 1.4 | 1830x1425x1735 | ||
| ZGS11-400 | 400 | 10 | Dyn11 | 570 | 4520/4300 | 1.3 | 1830x1435x1805 | |||
| ZGS11-500 | 500 | 10.5 | 680 | 5410/5150 | 1.2 | 1830x1445x1860 | ||||
| ZGS11-630 | 630 | 11 | 810 | 6200 | 1.1 | 4.5 | 1830x1445x1860 | |||
| ZGS11-800 | 800 | 980 | 7500 | 1 | 1830x1490x1860 | |||||
| ZGS11-1000 | 1000 | 1150 | 10300 | 1 | 1830x1675x2005 | |||||
| ZGS11-1250 | 1250 | 1360 | 12000 | 0.9 | 2100x1845x2035 | |||||
| ZGS11-1600 | 1600 | 1640 | 14500 | 0.8 | 2100x1885x2135 | |||||
| Note: Product shape, size and weight are data for a certain period of time, which may change due to design improvements. | ||||||||||
